Waterproof Metal Momentary Push Button Switch with Green LED Indicator
16mm 5A SPST Green Metal Push Button Switch — 12V Momentary (Panel-Mount)
Upgrade your dash, control panel, or project box with a compact, durable metal push button switch that’s simple to install and satisfying to press. This model features a momentary (non-latching) action and a bright Green 12V LED indicator—perfect for 12V automotive, marine, and DIY electronics.
Why You’ll Like It
- Clean, modern look: Brushed metal body with a low-profile round actuator.
- Built to last: 304 stainless-steel housing with a robust PC light guide/button cap.
- Instant feedback: Integrated Green LED (12V) shows status at a glance.
- Quick install: Fits a standard 16mm panel hole with the included mounting nut.
- Great for 12V systems: Ideal starter, horn, accessory, or reset trigger in cars, trucks, UTVs, boats, and bench projects.
What “Momentary” Means
Press to activate; release to turn off. It’s the right choice for functions you only need while holding the button—like triggering a relay, resetting a device, or engaging an accessory temporarily.
Typical Uses
- Starter/ignition trigger (via relay) or accessory enable in 12V automotive builds
- Horn, lights, winch control (with appropriate driver/relay)
- Bench power/reset button for hobby electronics and control panels
Tech Specs
| Mounting Hole | 16mm (panel-mount) |
| Action | Momentary (non-latching) |
| Indicator | Green LED, 12V |
| Body Material | Stainless steel (304) |
| Actuator/Light Guide | PC (polycarbonate) |
| System Amperage | 5A |
| Terminations | Panel switch with standard solder/quick-connect style lugs (varies by install) |
| Front-Panel Sealing | Water-resistant design suitable for automotive and outdoor panels |
| Color | Green (LED) |
What’s in the Box
- 16mm Green 12V momentary metal push button switch
- Panel mounting hardware (locking nut)
Installation Notes
- Cut a 16mm hole, seat the switch, and secure with the included nut.
- Wire the LED to 12V DC (observe polarity) and route the switch contacts through your load or relay as requiGreen.
- For high-current devices (motors, starters, light bars), drive them via a relay or controller rather than directly through the switch.
