4K HDMI Extender Over Single Cat5/6 - RX/TX Pair (4K@60Hz)

Extend Ultra HD Video with a 4K HDMI Extender

Enjoy stunning 4K video over long distances with this easy-to-use 4K HDMI extender kit. Using just a single Cat5 or Cat6 network cable, you can transmit HDMI signals up to 70 meters (229 feet)—perfect for home theaters, office setups, gaming rooms, or presentations.

Plug and Play HDMI Extender Over Cat5/6

This HDMI extender kit includes an HDMI transmitter (TX) and receiver (RX) pair, enabling simple point-to-point connectivity. No network setup required—just plug in and start watching. Send both HDMI and internet over the same cable with integrated pass-through, and enjoy reliable signal quality even over longer distances.

Key Features & Benefits

• Supports uncompressed 4K HDMI signals (3840x2160) at 24/25/30/50/60Hz
• Works with Cat5, Cat6, Cat6A, or Cat7 cables (CAT6A/7 for best range)
• Transmission distance: Up to 70m (230ft) for 1080P@60Hz over CAT6A/7
• Supports DDC, 3D, CEC pass-through, and 24-bit deep color
• HDCP 2.2 compliant — compatible with the latest HDMI devices
• Bi-directional IR control lets you operate devices from either end
• Power over Cable (PoC) for simple power—only one adapter needed
• Sturdy black aluminum alloy construction; easy to install and use

Technical Specifications

• Video Resolution: 3840x2160@24/25/30/50/60Hz
• Supported Audio: LPCM, DTS-HD, DTS-Audio, Dolby TrueHD 7.1CH, Dolby Digital 5.1CH
• HDMI Compliance: HDMI 2.0, HDCP 2.2
• Transmission Distance: Up to 229ft (70m) for 1080P@60Hz (with CAT6A/7)
• Input/Output Cable Length: Up to 8m (AWG24)
• Power Consumption: TX <4W, RX <4W (DC 5V/2A)
• Operating Temperature: -20~60℃; Storage: -30~70℃
• Dimensions: 106.0 x 99.0 x 26.2 mm
• Material: Aluminum alloy with crystal panel
• Electrostatic Protection: IEC61000-4-2, Contact and Air Discharge Level 3
• Humidity: 0~90% RH (non-condensing)
• Weight: TX: 210g, RX: 210g
• Treatment: Grit blast

What’s in the Box?

• HDMI Extender Transmitter (TX)
• HDMI Extender Receiver (RX)
• Power Adapter
• User Manual

Important Notes

• Does not support HDMI 1.2 and earlier devices
• For best performance, use high-quality Cat6A or Cat7 cables

Why Choose this HDMI Over Cat5/6 Extender?

Enjoy crisp, uncompressed video and audio in any room of your home or office. This long-range HDMI extender kit is perfect for anyone who wants an easy, reliable way to run HDMI signals over network cables—no specialized setup required. With support for full 4K@60Hz resolution, advanced audio standards, built-in power over cable, and plug-and-play simplicity, it’s the smart choice for home theaters, conference rooms, classrooms, and more.
