Finder Modular Contactor for 24V Control Panels, Lighting, and General Power Switching

Compact 24V Modular Contactor for Reliable Everyday Switching

The Finder Series 22 modular contactor is a compact, easy-to-install power switching solution for control panels, lighting circuits, pumps, HVAC control, and other building or equipment automation tasks. This model is a DPST-NO contactor, which means it provides 2 normally open poles for switching two lines at once when the coil is energized.

Designed for dependable everyday use, this modular contactor combines simple screw terminal wiring, quiet operation, and clear status visibility. It is a good choice for installers, maintenance techs, and panel builders who want a straightforward 24V contactor for switching higher current AC loads without moving up to a much larger industrial unit.

Easy-to-Use Contactor with LED and Mechanical Status Indicator

One of the most useful features of this Finder contactor is its built-in lighted indicator and mechanical indicator. These make it easier to confirm operating status at a glance during installation, troubleshooting, or routine maintenance.

The AC/DC silent coil design also helps reduce noise in control cabinets and electrical enclosures. That makes it especially useful in places where loud contactor chatter is undesirable, such as office lighting control, hotel energy systems, garden lighting, pump control, and similar building automation applications.

Built for Control Panels, DIN Rail Mounting, and Screw Terminal Wiring

This modular contactor is designed for DIN rail installation and fits standard 35 mm rail systems. Its screw terminal connections make field wiring secure and service-friendly, while the compact housing helps save space inside electrical panels.

Finder’s Series 22 contactors are built for continuous duty on both the coil and contacts, so they are well suited for applications where the contactor may remain energized for extended periods. The reinforced insulation between coil and contacts adds an extra level of separation for control and load circuits.

25A DPST-NO Contactor for Lighting, Pumps, and General Load Control

This 25 amp modular contactor is designed for switching resistive and slightly inductive loads, along with certain motor and lighting applications. The 2 Form A contact arrangement provides 2 normally open contacts, and the silver nickel (AgNi) contact material is intended for resistive loads, slightly inductive loads, and motor loads.

Because it uses a 24VAC/DC coil, it works well in systems where 24 volt control power is already available. That makes it a practical fit for low-voltage control circuits that need to switch 120V, 230V, or similar line-powered loads through a compact relay contactor.

Technical Highlights of the Finder Series 22 Contactor

The Finder 22.32.0.024.1320 is a 25A modular contactor with a 24VAC/DC coil, DPST-NO (2 Form A) contact arrangement, and nominal switching voltage up to 250VAC. It features a silent AC/DC coil with varistor protection, built-in LED and mechanical indication, screw terminals, and DIN rail mounting.

Additional technical data includes 83 mA coil current at 24V AC, 2 VA coil power, 289 ohm coil resistance, 30 ms operate time, 20 ms release time, and an operating temperature range of approximately -20 C to +50 C. The contactor is rated for continuous duty and uses silver nickel contacts. Must operate voltage is 19.2 VAC/DC, and must release voltage is 2.4 VAC/DC.

Typical Uses for a 24V Modular Power Contactor

This Finder modular contactor is well suited for switching lighting circuits, office and bathroom lighting control, car park and garden lighting, pump control, hotel room energy enabling systems, and other general-purpose automation or power control functions.

It can also be a good fit for OEM equipment, electrical service upgrades, control panel retrofits, and replacement of existing DIN rail contactors where a compact 25A 24V contactor with 2 normally open poles is needed.

Product Details

Manufacturer: Finder Relays, Inc.
Series: 22 Series
Manufacturer Part Number: 22.32.0.024.1320
Contact Configuration: DPST-NO (2 Form A)
Current Rating: 25A
Coil Voltage: 24VAC/DC
Switching Voltage: 250VAC nominal
Mounting Style: DIN rail modular contactor
Termination: Screw terminal
Features: Lighted indicator, mechanical indicator
Contact Material: Silver Nickel (AgNi)
