4-pin (2x2) Molex Mini Fit Jr. 0.165 MOLEX 39-01-2045 - White
6-Pin (2x3) Molex 165 Receptacle – Molex 39-01-2065High-Quality 6-Pin Molex Receptacle for Reliable Connections
The 6-pin Molex receptacle (Molex 39-01-2065) is a trusted solution for creating secure and dependable electrical connections in electronics projects and custom wiring applications. This 6-position Mini-Fit Jr. connector features a dual-row (2x3) configuration with a standard 4.2mm pitch, making it a popular choice for desktop PCs, graphics cards, modular power supplies, and more.
Key Benefits and Features
- Easy to Use: The Molex 6-pin connector housing has built-in polarization and a locking mechanism to ensure proper mating and avoid accidental disconnections—even in high-vibration environments.
- Durable and Safe: Made with UL 94V-0 rated black thermoplastic, this 6-pin crimp connector offers robust mechanical engagement and superior dielectric strength.
- Industry Compatibility: Fully compatible with Molex Mini-Fit Jr. female crimp pins, making it simple to design or repair custom cable assemblies.
- Widely Used: Frequently found on PC power supplies, PCI-Express power connectors, and consumer electronics for reliable power and signal delivery.
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | Molex (compatible) |
| Series | Mini-Fit Jr. 5557 |
| Part Type | Female Housing |
| Number of Positions | 6 (2x3 dual-row) |
| Pitch | 4.20mm (0.165") |
| Mounting Type | Free-Hanging / In-Line |
| Material | Thermoplastic, UL 94V-0 |
| Color | Black |
| Mating Connector Type | Male Header or Plug |
| Locking Mechanism | Polarization & Friction Lock |
| Operating Temperature | -40°C to +105°C |
| Terminals Used | Molex Mini-Fit Jr. Female Crimp Terminals (See here) |
| Applications | Desktop PCs, Video Cards, Power Supplies, Embedded Systems, Control Panels |
Get Everything You Need for Your Molex 6-Pin Power Connector
To complete your assembly, don’t forget to add Molex Mini-Fit Jr. 6-pin female crimp pins and, for easy servicing and repairs, consider the Molex Extraction Tool.
One 6-pin Molex 39-01-2065 connector housing per pack. Pins sold separately.
