19mm Blue 12V 5A 3-Position Illuminated Rotary Selector Switch

Simple control with clear indication

This compact 19mm rotary selector switch features a blue 12V LED ring and a smooth 3-position selector action, making it ideal for car dashboards, marine panels, DIY electronics and hobby setups. Its intuitive design ensures you instantly know which mode or circuit is active.

Features that matter

• Blue LED Ring illumination: Indicates status as desired, at a glance. The 12V LED light is independent of the switching contacts, and can be wired to users choice.
• Three positions: Offers selectable states - perfect for multi-mode setups or alternate controls.
• Compact 19mm mounting size: Fits into standard panels and retrofit applications.
• Durable metal build: Stainless-steel actuator and nickel-plated brass sleeve ensure long-term reliability.

Use cases

Whether you’re upgrading your vehicle’s lighting control, adding a selection switch to a gaming rig, or building a custom accessory panel in your RV or boat - this selector switch gives you a professional look and intuitive operation. The illuminated ring ensures visibility even in low-light conditions.

Technical specifications

• Mounting Hole: 19mm diameter
• Function: 3-position rotary selector (center position included)
• Illumination: Blue LED, 12 V
• Rated Current/Voltage: 5A up to 36 VDC
• Rated Power: 180 W (DC) / 1,250 W (AC)
• Protection Level: IP65 front face, IK08 impact rating
• Construction: 304 stainless actuator, nickel-plated brass sleeve, PA66 glass-filled housing
• Operating Temperature: -25 °C to +85 °C
• Wiring Diagram PDF

Important functional note

This switch contains two electrically isolated switchable poles, similar in appearance to a DPDT switch. However, it is not a true DPDT switch and should not be regarded as one.

• The two poles do not change state together in a synchronized 1:1 manner, as on a standard DPDT switch.

• One of the expected DPDT state combinations is not present.

Because of this, the switch cannot be used as a direct replacement for a DPDT switch. For example, it is not suitable for building a stereo A/B audio switch box or other applications that require both poles to switch together. Those applications would require additional circuitry such as relays or a microcontroller.

Only order or use this switch if you have verified that the exact contact combinations provided meet your application requirements.

Installation tips

• Drill a clean 19 mm cutout and secure the switch with the included mounting nut.
• Wire the LED ring to the 12 V supply; separately wire the selector terminals to your load or control circuit.
• If the circuit does not include a fuse, add an inline fuse appropriate for your load for safety.
