3.5mm Stereo Plug - Gold Plated, Metal Housing
3.5mm Stereo Plug – Gold Plated, Metal Housing
High-Quality 3.5mm Stereo Audio Plug for DIY Repairs & Projects
Upgrade or repair your headphones, audio cables, or custom electronics projects with this premium 3.5mm stereo plug featuring gold plated contacts and a sturdy metal housing. Designed for clear sound and extra durability, this 3.5mm audio connector fits most standard headphone jacks, portable audio devices, and DIY cable builds.
Key Features
- Gold plated 3.5mm plug for superior signal transfer and corrosion resistance
- Metal housing with black plated finish for a professional look and increased durability
- Recessed plug design – fits through most phone cases for convenient connectivity
- 3-conductor TRS configuration (Tip-Ring-Sleeve) for stereo audio applications
- Steel cable clamps provide a secure connection and relieve cable strain
- Phosphor bronze solder cup (tip), extended ring contact with hole punch, and crimp sleeve contact for consistent assembly
- PP insulating sleeve keeps connections separated and protected
- Suitable for headphone plug replacement, audio cable DIY, or general 1/8 inch stereo plug projects
Technical Specifications
- Type: 3.5mm (1/8 inch) stereo audio plug (TRS)
- Contacts: Gold plated for optimal conductivity
- Handle: Black plated metal
- Insulation: Polypropylene (PP) sleeve between contacts and housing
- Internal Clamp: Steel cable clamps to secure cable
- Assembly: Requires soldering and crimping
- Configuration:
- Tip: Phosphor bronze solder cup
- Ring: Extended contact with hole punch
- Sleeve: Crimp with cable clamp
Assembly Instructions
- Unscrew the metal housing and slide it over your cable.
- Solder your wires to the appropriate connections:
- Tip – Left audio channel
- Ring – Right audio channel
- Sleeve – Ground (shield)
- Crimp the steel cable clamps around your cable for strain relief.
- Ensure the polypropylene insulation is in place to prevent shorts.
- Screw the metal housing back on for a finished, secure connection.
Perfect for Everyday Use
Whether you're replacing a broken 3.5mm headphone plug, building custom audio cables, or upgrading your setup, this gold plated 3.5mm stereo plug delivers reliable performance and easy assembly for any home project.
